Product Specifications
Product nameMijia Air Conditioner Pro Eco 5-Star 1.0 HP Inverter
ModelASC-09WO/N1C5-MY
Energy efficiency rating5-Star
CSPF5.97
Energy efficiency label
Horsepower1.0HP
Cooling typeCool only
Cooling capacity (Btu/h)10000（2115-12000）
Cooling power (W)700（182-1100）
Circulating air volume (m³/h)620m³/h
Fixed speed/inverterInverter
Swing modeUp-Down and Left-Right Swing
Indoor unit noise (SH/M/SL)(dB(A))38/30/23
Outdoor unit noise (dB(A))48
*The air conditioner can adjust operation according to the ambient temperature, enhancing comfort while saving energy.
Power & Operating environment
Power plug specification16A
Power supply230V/50Hz
Applicable area10-15㎡
Design
Indoor unit dimensions (H/W/D)mm311/840/200
Outdoor unit dimensions (H/W/D)mm551/804/311
Indoor unit net weight (kg)9.9
Outdoor unit net weight (kg)21.8
ColourWhite
TypeSplit-Type Wall-Mounted Air Conditioner
Control methodsRemote control and smart control via app
Air conditioner installation guide
*Due to product optimisation, the above specifications may change. Please refer to the specifications on the product's nameplate.
Package contents
Indoor unit ×1Outdoor unit ×1Remote control x1Remote control holder x1Remote control holder cover x1User manual x1Screw set x1AAA battery x2Warranty notice x1Connector nut x4Drain hose x1*Due to product optimisation, the package contents may vary. Please refer to the actual product.
